News
NEW PRODUCTS - 2021-Up Ford Bronco Heavy Rate Rear Coilovers
ICON Vehicle Dynamics introduces our Heavy Rate Rear Coilover Spring for 2021-23 Ford Broncos equipped with ICON Coilovers. This is a dual rate coil that provides extra weight capacity for those who frequently load out their Broncos with extra gear and equipment while maintaining excellent on- and off-road performance characteristics. Heavy Rate Rear Coils are available as a retrofit kit for those who already own ICON rear coilovers, and as "Heavy Rate" versions of our assembled Coilovers and Complete Suspension Systems. LOAD UP FOR ADVENTURE ICON Heavy Rate Rear Coil Springs will result in a slight positive rake when the Bronco is unloaded. Actual numbers will vary for each individual Bronco. But the ICON 4-Door Badlands, which is equipped with the ICON Stage 8 Suspension System with Heavy Rate Rear Coils has a modest 1° positive rake with no extra cargo. Note that the Bronco is equpped with a 37" spare tire and an ICON Impact steel plate rear bumper. With a moderate load-out of 150 lbs. added to the rear cargo area, the Bronco squats just over a half inch, approaching a near-level rake of just 0.4°. To simulate a heavier load-out that is more typical of overlanders and others who carry lots of extra gear, we loaded the Bronco up with 280 lbs. in the cargo area and 520 lbs. in the rear seat area, for a total of 800 lbs. of extra weight. This lowered the rear ride height by 2" compared to unloaded, resulting in a slight -0.4° negative rake. Heavy Rate is a perfect all-around rear coil spring for those who either keep their Broncos heavily loaded full time, or only for occasional expeditions but want to maintain the best possible performance across various load-out scenarios. HEAVY RATE REAR COIL SPRING RETROFIT KIT 48200 21-23 BRONCO HEAVY RATE REAR COIL KIT The Heavy Rate Rear Coil Spring Kit is used to retrofit existing ICON Rear Coilovers to the Heavy Rate specification. The kit simply includes the replacement Heavy Rate coil springs. KEY FEATURES: Increased cargo load carrying capacity with less suspension squat. Unique ICON engineered dual rate coil spring Designed for full time large cargo loads Important: COIL CUP KIT #48201 MAY BE NEEDED Before ordering the Heavy Rate Coil Spring Retrofit Kit, identify which coil springs the coilovers were originally built with. The initial run of coilovers (early build) will require the new design Lower Coil Cup Kit, which may be ordered separately as p/n 48201. These early coil springs will be stamped with the number 148350 as shown in the image here. It may be necessary to spin the coil spring or use a small mirror to see the part number. Coilovers that bear the number 148351 on the coil spring already have the new design lower coil cup, and do not require the #48201 Coil Cup Kit to install the Heavy Rate springs. BRONCO HEAVY RATE REAR COILOVERS 2.5 VS HEAVY RATE REAR COILOVERS WITH INTERNAL RESERVOIRS 48613 21-23 BRONCO REAR 2.5 VS IR COILOVER KIT HEAVY RATE SPRING KEY FEATURES: Increased wheel travel and ride quality over stock Vehicle specific tuned for superior shock damping and control Heavy Rate dual rate coil spring engineered by ICON for heavier load-outs Adjustable up to 2-3" of rear lift height on non-Sasquatch or 1.25-2.25” of rear lift on Sasquatch Broncos 6061 Aircraft grade aluminum CNC machined components Corrosion resistant CAD plated shock bodies with 7/8" diameter shaft FK rod end bearings for extended longevity and minimal deflection Fully rebuildable and re-tunable 100% Bolt-on - no drilling, cutting or welding necessary for installation 2.5 VS HEAVY RATE REAR COILOVERS WITH REMOTE RESERVOIRS 48711 21-23 BRONCO REAR 2.5 VS RR COILOVER KIT HEAVY RATE SPRING KEY FEATURES: Increased wheel travel and ride quality over stock Vehicle specific tuned for superior shock damping and control Heavy Rate dual rate coil spring engineered by ICON for heavier load-outs Remote reservoirs maintain cooler operating temperatures during extended off-road use Adjustable up to 2-3" of rear lift height on non-Sasquatch or 1.25-2.25” of rear lift on Sasquatch Broncos 6061 Aircraft grade aluminum CNC machined components Corrosion resistant CAD plated shock bodies with 7/8" diameter shaft FK rod end bearings for extended longevity and minimal deflection Fully rebuildable and re-tunable 100% Bolt-on - no drilling, cutting or welding necessary for installation 2.5 VS HEAVY RATE REAR COILOVERS WITH CDCV 48711C 21-23 BRONCO REAR 2.5 VS RR CDCV COILOVER KIT HEAVY RATE SPRING KEY FEATURES: Increased wheel travel and ride quality over stock Vehicle specific tuned for superior shock damping and control Heavy Rate dual rate coil spring engineered by ICON for heavier load-outs Remote reservoirs maintain cooler operating temperatures during extended off-road use ICON CDCV equipped for 10 settings of external compression damping adjustment Adjustable up to 2-3" of rear lift height on non-Sasquatch or 1.25-2.25” of rear lift on Sasquatch Broncos 6061 Aircraft grade aluminum CNC machined components Corrosion resistant CAD plated shock bodies with 7/8" diameter shaft FK rod end bearings for extended longevity and minimal deflection Fully rebuildable and re-tunable 100% Bolt-on - no drilling, cutting or welding necessary for installation 2.5 VS HEAVY RATE REAR COILOVERS WITH CDEV 48711E 21-23 BRONCO REAR 2.5 VS RR CDEV COILOVER KIT HEAVY RATE SPRING? KEY FEATURES: Increased wheel travel and ride quality over stock Vehicle specific tuned for superior shock damping and control Heavy Rate dual rate coil spring engineered by ICON for heavier load-outs Remote reservoirs maintain cooler operating temperatures during extended off-road use ICON's CDE Valve technology allows for in vehicle adjustment of compression damping settings and active adjustment via the ICON Intelligent Control (IIC) ICON Intelligent Control (IIC) uses onboard sensors to monitor G-forces and movement of vehicle chassis along with user defined settings to actively make near instantaneous compression damping changes Adjustable up to 2-3" of rear lift height on non-Sasquatch or 1.25-2.25” of rear lift on Sasquatch Broncos Unique ICON engineered triple rate coil springs 6061 Aircraft grade aluminum CNC machined components Corrosion resistant CAD plated shock bodies with 7/8" diameter shaft FK rod end bearings for extended longevity and minimal deflection Fully rebuildable and re-tunable 100% Bolt-on - no drilling, cutting or welding necessary for installation COMPLETE BRONCO SUSPENSION SYSTEMS WITH HEAVY RATE REAR COILOVERS ICON is also offering each version of our Bronco Complete Coilover Suspension Systems, Stages 3 through 8, in a variation that includes the Heavy Rate Rear Coilovers. If you are already familiar with these suspension systems, simply add an "X" to the end of the suspension system's Kit Number (or "K" number as we call them at ICON), and that will denote the kit comes with the Heavy Rate rear coilovers. You may choose to set up your website eCommerce systems with the Heavy Rate rear coilover option rather than creating a whole new product listing for each of these variants. In case you do choose to create new listings for each Stage, we have included all of the "Kit Images" in the downloadable Images file. Note that they are identical to the normal rate versions of the kit images; only the file names are different to denote the K***X kit number. A complete list of Heavy Rate Suspension System Stages, along with the included components for each kit, is contained in the Price & Spec Sheet downloadable file. For quick reference, they are also listed below: STAGE 3 WITH X-RATE REAR COILOVERS K40003TX 21-23 BRONCO NON-SASQ 3-4" LIFT STAGE 3 SUSPENSION SYSTEM TUBULAR HEAVY RATE 48600 21-23 BRONCO FRONT 2.5 VS IR COILOVER KIT 48400DJ 21-23 BRONCO TUBULAR UCA DJ PRO KIT 48613 21-23 BRONCO REAR 2.5 VS IR COILOVER KIT HEAVY RATE SPRING K40003X 21-23 BRONCO NON-SASQ 3-4" LIFT STAGE 3 SUSPENSION SYSTEM BILLET HEAVY RATE 48600 21-23 BRONCO FRONT 2.5 VS IR COILOVER KIT 48500DJ 21-23 BRONCO BILLET UCA DJ PRO KIT 48613 21-23 BRONCO REAR 2.5 VS IR COILOVER KIT HEAVY RATE SPRING STAGE 4 WITH X-RATE REAR COILOVERS K40004TX 21-23 BRONCO NON-SASQ 3-4" LIFT STAGE 4 SUSPENSION SYSTEM TUBULAR HEAVY RATE 48700 21-23 BRONCO FRONT 2.5 VS RR COILOVER KIT 48400DJ 21-23 BRONCO TUBULAR UCA DJ PRO KIT 611072 21-23 BRONCO HOSE ROUTE KIT OEM REAR LINK 1.9" 48711 21-23 BRONCO REAR 2.5 VS RR COILOVER KIT HEAVY RATE SPRING K40004X 21-23 BRONCO NON-SASQ 3-4" LIFT STAGE 4 SUSPENSION SYSTEM BILLET HEAVY RATE 48700 21-23 BRONCO FRONT 2.5 VS RR COILOVER KIT 48500DJ 21-23 BRONCO BILLET UCA DJ PRO KIT 611072 21-23 BRONCO HOSE ROUTE KIT OEM REAR LINK 1.9" 48711 21-23 BRONCO REAR 2.5 VS RR COILOVER KIT HEAVY RATE SPRING STAGE 5 WITH X-RATE REAR COILOVERS K40005TX 21-23 BRONCO NON-SASQ 3-4" LIFT STAGE 5 SUSPENSION SYSTEM TUBULAR HEAVY RATE 48700 21-23 BRONCO FRONT 2.5 VS RR COILOVER KIT 48400DJ 21-23 BRONCO TUBULAR UCA DJ PRO KIT 44000T 21-23 BRONCO TUBULAR REAR LOWER LINK KIT 611073 21-23 BRONCO HOSE ROUTE KIT REAR LINK 1.75" 48711 21-23 BRONCO REAR 2.5 VS RR COILOVER KIT HEAVY RATE SPRING K40005X 21-23 BRONCO NON-SASQ 3-4" LIFT STAGE 5 SUSPENSION SYSTEM BILLET HEAVY RATE 48700 21-23 BRONCO FRONT 2.5 VS RR COILOVER KIT 48500DJ 21-23 BRONCO BILLET UCA DJ PRO KIT 44000 21-23 BRONCO BILLET REAR LOWER LINK KIT 48711 21-23 BRONCO REAR 2.5 VS RR COILOVER KIT HEAVY RATE SPRING STAGE 6 WITH X-RATE REAR COILOVERS K40006TX 21-23 BRONCO NON-SASQ 3-4" LIFT STAGE 6 SUSPENSION SYSTEM TUBULAR HEAVY RATE 48700C 21-23 BRONCO FRONT 2.5 VS RR CDCV COILOVER KIT 48400DJ 21-23 BRONCO TUBULAR UCA DJ PRO KIT 44000T 21-23 BRONCO TUBULAR REAR LOWER LINK KIT 611073 21-23 BRONCO HOSE ROUTE KIT REAR LINK 1.75" 48711C 21-23 BRONCO REAR 2.5 VS RR CDCV COILOVER KIT HEAVY RATE SPRING K40006X 21-23 BRONCO NON-SASQ 3-4" LIFT STAGE 6 SUSPENSION SYSTEM BILLET HEAVY RATE 48700C 21-23 BRONCO FRONT 2.5 VS RR CDCV COILOVER KIT 48500DJ 21-23 BRONCO BILLET UCA DJ PRO KIT 44000 21-23 BRONCO BILLET REAR LOWER LINK KIT 48711C 21-23 BRONCO REAR 2.5 VS RR CDCV COILOVER KIT HEAVY RATE SPRING STAGE 7 WITH X-RATE REAR COILOVERS K40007TX 21-23 BRONCO NON-SASQ 3-4" LIFT STAGE 7 SUSPENSION SYSTEM TUBULAR HEAVY RATE 48700C 21-23 BRONCO FRONT 2.5 VS RR CDCV COILOVER KIT 48400DJ 21-23 BRONCO TUBULAR UCA DJ PRO KIT 44100T 21-23 BRONCO TUBULAR REAR UPPER LINK KIT 44000T 21-23 BRONCO TUBULAR REAR LOWER LINK KIT 611073 21-23 BRONCO HOSE ROUTE KIT REAR LINK 1.75" 44200T 21-23 BRONCO REAR ADJ TRACK BAR KIT 48711C 21-23 BRONCO REAR 2.5 VS RR CDCV COILOVER KIT HEAVY RATE SPRING K40007X 21-23 BRONCO NON-SASQ 3-4" LIFT STAGE 7 SUSPENSION SYSTEM BILLET HEAVY RATE 48700C 21-23 BRONCO FRONT 2.5 VS RR CDCV COILOVER KIT 48500DJ 21-23 BRONCO BILLET UCA DJ PRO KIT 44100 21-23 BRONCO BILLET REAR UPPER LINK KIT 44000 21-23 BRONCO BILLET REAR LOWER LINK KIT 44200T 21-23 BRONCO REAR ADJ TRACK BAR KIT 48711C 21-23 BRONCO REAR 2.5 VS RR CDCV COILOVER KIT HEAVY RATE SPRING STAGE 8 WITH X-RATE REAR COILOVERS K40008TX 21-23 BRONCO NON-SASQ 3-4" LIFT STAGE 8 SUSPENSION SYSTEM TUBULAR HEAVY RATE 48700E 21-23 BRONCO FRONT 2.5 VS RR CDEV COILOVER KIT 48400DJ 21-23 BRONCO TUBULAR UCA DJ PRO KIT 44100T 21-23 BRONCO TUBULAR REAR UPPER LINK KIT 44000T 21-23 BRONCO TUBULAR REAR LOWER LINK KIT 611073 21-23 BRONCO HOSE ROUTE KIT REAR LINK 1.75" 44200T 21-23 BRONCO REAR ADJ TRACK BAR KIT 43501 21-23 BRONCO IIC INSTALL KIT 48711E 21-23 BRONCO REAR 2.5 VS RR CDEV COILOVER KIT HEAVY RATE SPRING K40008X 21-23 BRONCO NON-SASQ 3-4" LIFT STAGE 8 SUSPENSION SYSTEM BILLET HEAVY RATE 48700E 21-23 BRONCO FRONT 2.5 VS RR CDEV COILOVER KIT 48500DJ 21-23 BRONCO BILLET UCA DJ PRO KIT 44100 21-23 BRONCO BILLET REAR UPPER LINK KIT 44000 21-23 BRONCO BILLET REAR LOWER LINK KIT 44200T 21-23 BRONCO REAR ADJ TRACK BAR KIT 43501 21-23 BRONCO IIC INSTALL KIT 48711E 21-23 BRONCO REAR 2.5 VS RR CDEV COILOVER KIT HEAVY RATE SPRING
Read More
NEW PRODUCTS - 2022-Up Toyota Landcruiser 300 Coilovers, Shocks and UCAs
ICON Vehicle Dynamics announces our complete line of suspension components and complete suspension systems for the 2022-23 Toyota Land Cruiser 300 Series. Components include ICON 2.5 VS Series Front Coilovers and Rear Shocks as well as ICON billet Front Upper Control Arms. Coilovers & Shocks are available in either non-Reservoir (front only), Remote Reservoir or Remote Reservoir with our CDCV Compression Damping Control Valve technology for adjustable damping performance. Our Stages 1 to 3 Complete Suspension Systems make specifying and ordering complete kits easy for any customer's needs and budget. NOTE: 2022-23 Land Cruiser 300 Series is not sold in North American markets. BILLET UPPER CONTROL ARMS WITH DELTA JOINT™ 58571DJ 22-UP LC 300 BILLET UCA DJ KIT KEY FEATURES: ICON Delta Joint CNC Machined 6061 Billet Aluminum Construction Quality PTFE-lined ¾” FK Rod Ends On-Vehicle Adjustable For Quick And Precise Alignment Caster and Camber Adjustability Allows For Fine Tuning Of Vehicle Handling Matte Anodized Finish Provides Exceptional Corrosion Resistance O-ring Sealed Delta Joint Cover Cap For Additional Protection From The Elements 2.5 VS INTERNAL RESERVOIR FRONT COILOVERS 58661 22-UP LC 300 2.5 VS IR COILOVER KIT KEY FEATURES: Increased wheel travel and ride quality over stock Improved vehicle dynamics and decreased body roll Height adjustable coilovers provide 1.5 to 3.0" of lift height Vehicle-specific tuned front and rear shocks provide superior damping and control Corrosion resistant CAD plated coilover shock bodies with 7/8" shafts CDCV technology allows for quick and easy compression damping adjustment without the need for tools Shocks are fully rebuildable and revalveable Bolt-on design means no cutting or welding necessary for install TECH INFO: SHOCKS ARE FULLY SERVICEABLE. LIFT HEIGHTS INDICATED ARE FOR A STOCK EQUIPPED VEHICLE. ADVERTISED LIFT HEIGHT RANGES ARE FOR A STOCK EQUIPPED VEHICLE. INCREASING WEIGHT OF VEHICLE DUE TO ACCESSORIES WILL ALTER LIFT RANGE. NOT COMPATIBLE WITH VEHICLES EQUIPPED WITH LOAD-LEVELING REAR HEIGHT CONTROL AIR SUSPENSION. 2.5 VS RR FRONT COILOVERS WITH CDCV 58761C 22-UP LC 300 2.5 VS RR CDCV COILOVER KIT KEY FEATURES: Increased wheel travel and ride quality over stock Improved vehicle dynamics and decreased body roll Height adjustable coilovers provide 1.5 to 3.0" of lift height Vehicle-specific tuned front and rear shocks provide superior damping and control Corrosion resistant CAD plated coilover shock bodies with 7/8" shafts Remote reservoir increases shock oil volume and heat dissipation CDCV technology allows for quick and easy compression damping adjustment without the need for tools Shocks are fully rebuildable and revalveable Bolt-on design means no cutting or welding necessary for install TECH INFO: SHOCKS ARE FULLY SERVICEABLE. LIFT HEIGHTS INDICATED ARE FOR A STOCK EQUIPPED VEHICLE. ADVERTISED LIFT HEIGHT RANGES ARE FOR A STOCK EQUIPPED VEHICLE. INCREASING WEIGHT OF VEHICLE DUE TO ACCESSORIES WILL ALTER LIFT RANGE. 0"-2" 2.5 VS REMOTE RESERVOIR REAR SHOCKS 57827P 22-23 LC 300 0-2" REAR 2.5 VS RR PAIR KEY FEATURES: Increased wheel travel and ride quality over stock Improved vehicle dynamics and decreased body roll Extended shock travel allows for 0 to 2" of lift height Vehicle-specific tuned shocks provide superior damping and control 2.5 Aluminum Series rear shocks feature one-piece impact extruded aluminum cylinders for excellent corrosion resistance and consistent finish Remote reservoir increases shock oil volume and heat dissipation CDCV technology allows for quick and easy compression damping adjustment without the need for tools Shocks are fully rebuildable and revalveable Bolt-on design means no cutting or welding necessary for install TECH INFO: SHOCKS ARE FULLY SERVICEABLE. LIFT HEIGHTS INDICATED ARE FOR A STOCK EQUIPPED VEHICLE. ADVERTISED LIFT HEIGHT RANGES ARE FOR A STOCK EQUIPPED VEHICLE. INCREASING WEIGHT OF VEHICLE DUE TO ACCESSORIES WILL ALTER LIFT RANGE. NOT COMPATIBLE WITH VEHICLES EQUIPPED WITH LOAD-LEVELING REAR HEIGHT CONTROL AIR SUSPENSION 0"-2" 2.5 VS RR REAR SHOCKS WITH CDCV 57827CP 22-23 LC 300 0-2" REAR 2.5 VS RR CDCV PAIR KEY FEATURES: Increased wheel travel and ride quality over stock Improved vehicle dynamics and decreased body roll Extended shock travel allows for 0 to 2" of lift height Vehicle-specific tuned shocks provide superior damping and control 2.5 Aluminum Series rear shocks feature one-piece impact extruded aluminum cylinders for excellent corrosion resistance and consistent finish Remote reservoir increases shock oil volume and heat dissipation CDCV technology allows for quick and easy compression damping adjustment without the need for tools Shocks are fully rebuildable and revalveable Bolt-on design means no cutting or welding necessary for install TECH INFO: SHOCKS ARE FULLY SERVICEABLE. LIFT HEIGHTS INDICATED ARE FOR A STOCK EQUIPPED VEHICLE. ADVERTISED LIFT HEIGHT RANGES ARE FOR A STOCK EQUIPPED VEHICLE. INCREASING WEIGHT OF VEHICLE DUE TO ACCESSORIES WILL ALTER LIFT RANGE. NOT COMPATIBLE WITH VEHICLES EQUIPPED WITH LOAD-LEVELING REAR HEIGHT CONTROL AIR SUSPENSION. STAGE 1 SUSPENSION SYSTEM K53261 22-23 LAND CRUISER 300 SERIES 1-3" STAGE 1 SUSPENSION SYSTEM INCLUDES: 58661 1 22-23 LC 300 2.5 VS IR COILOVER KIT 57827P 1 22-23 LC 300 0-2" REAR 2.5 VS RR PAIR TECH INFO: APPLICATION NOTES: 55,85,142 TIRE & WHEEL: 35X12.50 ON 8.5" WIDE WHEEL W/ 5.75" BACKSPACE STAGE 2 SUSPENSION SYSTEM K53262 22-23 LAND CRUISER 300 SERIES 1-3" STAGE 2 SUSPENSION SYSTEM BILLET INCLUDES 58761 1 22-23 LC 300 2.5 VS RR COILOVER KIT 58571DJ 1 22-23 LC 300 BILLET UCA DJ PRO KIT 57827P 1 22-23 LC 300 0-2" REAR 2.5 VS RR PAIR TECH INFO: APPLICATION NOTES: 55,85,142 TIRE & WHEEL: 35X12.50 ON 8.5" WIDE WHEEL W/ 5.75" BACKSPACE STAGE 3 SUSPENSION SYSTEM K53263 22-23 LAND CRUISER 300 SERIES 1-3" STAGE 3 SUSPENSION SYSTEM BILLET INCLUDES: 58761C 1 22-23 LC 300 2.5 VS RR CDCV COILOVER KIT 58571DJ 1 22-23 LC 300 BILLET UCA DJ PRO KIT 57827CP 1 22-23 LC 300 0-2" REAR 2.5 VS RR CDCV PAIR TECH INFO: APPLICATION NOTES: 55,85,142 TIRE & WHEEL: 35X12.50 ON 8.5" WIDE WHEEL W/ 5.75" BACKSPACE
Read More
NEW PRODUCTS - 2023+ Ford Super Duty Centerline Steering Stabilizer Kit
ICON Vehicle Dynamics has developed our two most popular performance steering stabilizer kits for the 2023 and newer Ford Super Duty Pickup platform. Both the ICON Dual 2.0 Steering Stablizer Kit and the ICON 2.5 Centerline Steering Stablizer are now available for the current models of Ford 3/4-ton and 1-ton trucks. Through-Shaft Steering Stabilizer Kit 65053 23 FSD Centerline Steering Stabilizer The ICON Centerline Steering Stabilizer features a through-shaft design to eliminate the push/pull sensation associated with traditional steering stabilizers, resulting in more consistent damping and symmetrical steering feel throughout the input range. The large 2.5-inch diameter stabilizer body and piggyback reservoir increases fluid volume to prevent performance fade due to heat and cavitation. This unit provides a significant increase in steering damping compared to the stock equipment, for an improved driving experience with both stock size and oversize aftermarket wheels and tires. The stabilizer body shares components with ICON's proven 2.5 Series shock absorbers, meaning the unit is fully rebuildable. 2.5 Series features a 6061 hard anodized aluminum shock body for excellent corrosion resistance and a beefy 7/8” chrome plated induction-hardened steel shaft. FK Rod End bearings provide precise function & feel throughout steering range. Installation is 100% bolt-on using common hand tools and should be an easy job for both professional mechanics and experienced DIY'ers. Key Features: Through shaft design eliminates the push/pull sensation associated with traditional stabilizers Provides symmetrical steering feel throughout input range Drastically increased steering damping over stock unit Fully rebuildable ICON Vehicle Dynamics 2.5 Series shock Piggyback reservoir design 6061 hard anodized aluminum shock body provides excellent corrosion resistance 7/8” chrome plated induction-hardened steel shaft 5WT shock oil for consistent suspension damping along a wide temperature range FK Rod End bearings for precise function & feel throughout steering range 100% bolt-on installation Tech Info: TECH NOTE: After installation, cycle steering left and right to ensure full range of steering is achievable and stabilizer is installed correctly TECH NOTE: Use ICON 1” front bump stop spacers, part # 61112, unless the suspension system that you are using calls for larger bump stop spacers. If using a non-ICON configuration, cycle the suspension to verify that the stabilizer does not make contact upon full compression. TECH NOTE: Mounts over stock front differential cover, not compatible with most aftermarket covers. TECH NOTE: Not compatible with aftermarket tie rods TECH NOTE: Only compatible with 4WD models Dual Steering Stabilizer Kit 65002 23 Ford Super Duty Dual Stabilizer Kit The ICON Dual Steering Stabilizer System is designed to minimize bump steer feedback and smooth out terrain feedback through the steering system. This kit facilitates mounting dual ICON 2.0 Aluminum Series Steering Shock Absorbers (sold separately) in an opposing configuration. This strategy cancels out the push/pull effect from the internal pressures of the two shocks, providing far greater steering damping compared to single, similarly sized steering stabilizer. Driver "feel" through the steering wheel is greatly improved and the truck tracks straight down the road. This system bolts to the factory differential cover and wraps around the axle for a secure fit without cutting, welding or drilling. The Shock Absorbers are connected to the tire rod with black anodized billet aluminum clamps for a secure fit and clean finish. Key Features: Dual opposing design eliminates the push/pull sensation associated with traditional stabilizers Dual ICON 2.0 Aluminum Series Steering Shocks offer increased steering damping over stock unit (shocks sold separately) Provides symmetrical steering feel throughout input range CNC laser cut steel components Semi-gloss black powder coat finish 6061 billet aluminum tie rod clamps, anodized for corrosion resistance 100% bolt-on installation Tech Info: TECH NOTE: Requires ICON Steering Stabilizer Shock Part # 36511 (Qty 2) TECH NOTE: Only compatible with 4WD models TECH NOTE: Not compatible with F-450 or F-550 TECH NOTE: 2017-2023 trucks require minimum of 2" bump stop spacer. ICON Part # 64037 TECH NOTE: Not recommended for use with stock height trucks 2.0 Steering Stabilizer (2 Required) 36511 99-UP FSD 4WD Stabilizer (Dual Opposing) 2.0 VS IR
Read More
NEW PRODUCT | CDEV 2.5 & 3.0 SYSTEMS FOR 22-UP TOYOTA TUNDRA
ICON Vehicle Dynamics is excited to announce the addition of CDEV-equipped versions of our 2.5 and 3.0 Series Performance Shocks and Coilovers to our complete line of suspension systems and upgrades for 2022 and up Toyota Tundra, as well as corresponding additions to our complete suspension system "Stage" kits. ICON's cutting edge Compression Damping Electronic Valve (CDEV), powered by the amazing ICON Intelligent Control (IIC) module, is the pinnacle of lightining-fast, on-the-fly suspension adjustment that instantly optimizes shock performance for every change in speed and terrain. Set your custom parameters or use a variety of pre-loaded performance profiles via the ICON app on your phone, which communicates wirelessly to the IIC control module via Bluetooth. These CDEV-equipped components complement ICON's existing, comprehensive line of suspension products for Ford Super Duty, which already includes performance front coil and rear leaf springs for a variety of lift heights, performance suspension links and radius arm conversions, performance shock absorbers, and up to 6 Stages of complete suspension systems. Now you can upgrade any ICON suspension solution for FSD to include the amazing technology and capabilities of the Compression Damping Electronic Valves powered by ICON Intelligent Control! COMPONENTS 58770E 22-23 TUNDRA 2.5 VS RR CDEV COILOVER KIT 57840EP 22-23 TUNDRA 0-1" REAR 2.5 VS CDEV RR PAIR 58775E 22-23 TUNDRA 3.0 VS RR CDEV COILOVER KIT 57845EP 22-23 TUNDRA REAR 3.0 VS RR CDEV PAIR 53508 22-23 TUNDRA IIC INSTALL KIT SUSPENSION SYSTEMS K53214 22-23 TUNDRA 1.25-3.25" STAGE 4 3.0 SUSP SYSTEM BILLET K53214T 22-23 TUNDRA 2-3.25" STAGE 4 3.0 SUSP SYSTEM TUBULAR K53215 22-23 TUNDRA 1.25-3.25" STAGE 5 3.0 SUSP SYSTEM BILLET K53215T 22-23 TUNDRA 2-3.25" STAGE 5 3.0 SUSP SYSTEM TUBULAR K53202 22-23 TUNDRA 1.25-3.5" STAGE 12 SUSP SYSTEM BILLET K53202T 22-23 TUNDRA 2-3.5" STAGE 12 SUSP SYSTEM TUBULAR K53203 22-23 TUNDRA 1.25-3.5" STAGE 13 SUSP SYSTEM BILLET K53203T 22-23 TUNDRA 2-3.5" STAGE 13 SUSP SYSTEM TUBULAR Keep reading for detailed information on each of these exciting new CDEV-equipped products! 2.5 & 3.0 CDEV SHOCKS & COILOVERS 22-23 TOYOTA TUNDRA 2.5 CDEV FRONT COILOVERS 58770E 22-23 TUNDRA 2.5 VS RR CDEV COILOVER KIT The ICON Vehicle Dynamics V.S. Series 2.5” remote reservoir coilover shocks w/ CDCV are an incredible upgrade for the front end of the 2022 and newer Toyota Tundra. ICON’s Vehicle-specific valving provides a sport tuned feel on and off-road while offering 1-3” of lift height adjustability for use of larger, more aggressive wheel and tire combinations. ICON's larger 2.5” shock body and increased piston area over stock components provides improved damping ability and outstanding ride characteristics across varying types of terrain. Remote reservoirs ensure optimum performance by increasing the duration of consistent damping regardless of situation, keeping the shocks at a cooler operating temperature during heavy use. The ICON CDEV with IIC (sold separately) provides on-the-fly, user configurable suspension tuning that reacts in real time, further enhancing the venicle's off-road speed, control and comfort through any terrain. ICON's CDE Valve technology allows for in vehicle adjustment of compression damping settings and active adjustment via the ICON Intelligent Control (IIC) Increased wheel travel and ride quality over stock Vehicle specific tuned for superior shock damping and control Adjustable for 1.25 - 3.5" of lift height over stock ICON engineered custom coil springs External reservoirs to attain cooler operating temperatures during extended off-road use 6061 Aircraft grade aluminum CNC machined components Corrosion resistant CAD plated shock bodies with 7/8" induction hardened, chrome plated shafts FK rod end bearings for extended longevity and minimal deflection Bolt-on kit - no cutting or welding necessary for installation 100% Rebuildable and revalveable 22-23 TOYOTA TUNDRA 2.5 CDEV REAR SHOCKS 57840EP 22-23 TUNDRA 0-1" REAR 2.5 VS CDEV RR PAIR ICON Vehicle Specific (V.S.) 2.5 Aluminum Series shocks with CDEV are designed and built to give your vehicle outstanding performance off-road and a smooth ride on the street. These shocks are configured specifically for each application in both length and damping tune. For piggyback and specific remote reservoir applications, ICON'S unique use of a 6061 billet aluminum manifold a few inches below the top cap of the shock creates an internal Bump Zone that when used creates an additional 20% of damping force. This additional force helps prevent harsh bottom outs and controls the suspension when compressing at high velocity. The ICON CDEV with IIC (sold separately) provides on-the-fly, user configurable suspension tuning that reacts in real time, further enhancing the venicle's off-road speed, control and comfort through any terrain. ICON's CDE Valve technology allows for in vehicle adjustment of compression damping settings and active adjustment via the ICON Intelligent Control (IIC) ICON’s internal “Bump Zone” increases damping by 20% to provide more control as the shock approaches full compression One-piece, hard anodized, impact extruded aluminum cylinders offer excellent corrosion resistance and consistent finish Remote reservoir design improves heat dissipation to reduce shock fade during prolonged use Premium grade 5WT shock oil for consistent suspension damping along a wide temperature range Nitrogen charged monotube design with piggyback reservoir One-piece digressive piston design with vehicle specific valving for unsurpassed performance and ride quality on and off-road 7/8” diameter induction hardened, chrome plated shock shaft PTFE lined spherical bearings and application specific mounting hardware 6061 aircraft grade aluminum CNC machined components 100% Rebuildable and revalveable 22-23 TOYOTA TUNDRA 3.0 CDEV FRONT COILOVERS 58775E 22-23 TUNDRA 3.0 VS RR CDEV COILOVER KIT ICON 3.0 Series Coilovers with CDEV are designed to take the off-road capability of the 2022 and newer Toyota Tundra to new levels by increasing wheel travel and significantly improving the damping ability of the front shocks. Compared to the 2.5” diameter coilovers the 3.0 Series shocks see a piston surface area increase of 50% in the ride zone, and 100% in the “Bump Zone”. This translates into increased stability and vehicle control at the extremes of off-road use, with benefits also making themselves apparent in on-road driving conditions. The multi-stage hydraulic Bump Zone featured in these 3.0 Series shocks exponentially increases bottom-out resistance as the shock travels through the last 40% of travel, keeping vehicle dynamics in check during those hard hits or unexpected obstacles. The ICON CDEV with IIC (sold separately) provides on-the-fly, user configurable suspension tuning that reacts in real time, further enhancing the venicle's off-road speed, control and comfort through any terrain. ICON's CDE Valve technology allows for in vehicle adjustment of compression damping settings and active adjustment via the ICON Intelligent Control (IIC) Significant increase in damping ability for excellent performance in extreme off-road conditions 7/8" diameter induction hardened, chrome plated shock shaft Multi stage CAD plated shock body with hard anodized piston and top cap Fully serviceable Increased wheel travel and vehicle specific valving provides comfortable and consistent ride quality on and off-road Adjustable coilovers provide 1.25 - 3.25” of front lift height over stock Direct bolt-in to OEM shock location makes for an easy install ICON’s multi-stage, tuneable hydraulic “Bump Zone” exponentially increases bottom-out resistance in the last 40% of compression travel 10” aluminum reservoirs provide generous oil and nitrogen volume for consistent damping with temperature increase High quality ICON-engineered coil springs offer improved performance PTFE lined COM12 spherical bearings ensure maximum strength and durability 22-23 TOYOTA TUNDRA 3.0 CDEV REAR SHOCKS 57845EP 22-23 TUNDRA REAR 3.0 VS RR CDEV PAIR ICON's 3.0 Series Rear Shocks are designed to take the off-road capability of the 2022 and newer Toyota Tundra to new levels by increasing wheel travel by up to 20% and significantly improving the damping ability of the rear shocks, while being compatible with rear lift heights up to 1" over stock. 3.0 Series shocks boast 50% more piston surface area compared to 2.5 Series shocks. This translates into increased stability and vehicle control at the extremes of off-road use, with benefits also making themselves apparent in on-road driving conditions. Increased internal oil volume and more external surface area compared to 2.5 Series Shocks offer improved heat dissipation and resistance to shock fade under hard use. The ICON CDEV with IIC (sold separately) provides on-the-fly, user configurable suspension tuning that reacts in real time, further enhancing the venicle's off-road speed, control and comfort through any terrain. ICON's CDE Valve technology allows for in vehicle adjustment of compression damping settings and active adjustment via the ICON Intelligent Control (IIC) 20% increase in rear suspension travel compared to stock Compatible with up to 1” of rear lift on most models Vehicle specific design and tuning for superior shock damping and control 3.0” Body diameter for increased oil volume and larger piston area CNC machined 6061 aluminum components with a black anodized finish PTFE lined spherical bearings for extended longevity and minimal deflection 7/8” diameter induction hardened, chrome plated shock shafts Corrosion resistant CAD plated steel shock bodies Fully Rebuildable and Re-tunable 22-23 TOYOTA TUNDRA IIC MODULE & INSTALL KIT 53508 22-23 TUNDRA IIC INSTALL KIT ICON Intelligent Control (IIC) is the computer that monitors, analyzes, and processes data in real-time. Information from the onboard G-force sensor and Gyroscope perform calculations based on algorithms and user-defined settings to predict terrain and wheel position. IIC has the capability to collect information at over 1000 times per second, process the data and make adjustments, then deliver those changes to Compression Damping Electronic Valve (CDEV) in the shock absorbers in under 40 milliseconds. IIC also works as a data driver to connect the user to ICON’s proprietary mobile App interface for monitoring and adjusting shock settings. The IIC is mounted to the 2022 and newer Toyota Tundra using application specific mounting brackets, hardware and wire harnesses, ensuring an easy and clean looking install. Offers selectable active shock damping adjustment as well as manual adjustment of baseline settings without exiting vehicle Onboard sensors monitor G-forces and movement of vehicle chassis Performs calculations based on sensor inputs, custom algorithms, and user defined settings at a rate of over 1000 times per second Sends necessary damping adjustments to CDEV shocks that react in under 40 milliseconds User interface provided by IIC Mobile App via Bluetooth connection to iOS device Mobile app offers preconfigured “Drive Modes” as well as the ability to create custom presets Also functions as a data logger for time, speed, distance, and G-force allowing you to record data from your trips Application specific mounting brackets, hardware and wire harnesses 2.5 CDEV SUSPENSION STAGES 22-23 TOYOTA TUNDRA 2.5 STAGE 12 SUSPENSION SYSTEMS K53202T 22-23 TUNDRA 2-3.5" STAGE 12 SUSPENSION SYSTEM TUBULAR 58770E 1 22-23 TUNDRA 2.5 VS RR CDEV COILOVER KIT 58461DJ 1 22-23 TUNDRA TUBULAR UCA DJ KIT 55154 1 22-23 TUNDRA SWAY BAR DROP KIT 57840EP 1 22-23 TUNDRA 0-1" REAR 2.5 VS CDEV RR PAIR 53508 1 22-23 TUNDRA IIC INSTALL KIT K53202 22-23 TUNDRA 1.25-3.5" STAGE 12 SUSPENSION SYSTEM BILLET 58770E 1 22-23 TUNDRA 2.5 VS RR CDEV COILOVER KIT 58561DJ 1 22-23 TUNDRA BILLET UCA DJ PRO KIT 55154 1 22-23 TUNDRA SWAY BAR DROP KIT 57840EP 1 22-23 TUNDRA 0-1" REAR 2.5 VS CDEV RR PAIR 53508 1 22-23 TUNDRA IIC INSTALL KIT 22-23 TOYOTA TUNDRA 2.5 STAGE 13 SUSPENSION SYSTEMS K53203T 22-23 TUNDRA 2-3.5" STAGE 13 SUSPENSION SYSTEM TUBULAR 58770E 1 22-23 TUNDRA 2.5 VS RR CDEV COILOVER KIT 58461DJ 1 22-23 TUNDRA TUBULAR UCA DJ KIT 55154 1 22-23 TUNDRA SWAY BAR DROP KIT 54002 1 22-23 TUNDRA BILLET REAR LOWER LINK KIT 54102 1 22-23 TUNDRA BILLET REAR UPPER LINK KIT 57840EP 1 22-23 TUNDRA 0-1" REAR 2.5 VS CDEV RR PAIR 53508 1 22-23 TUNDRA IIC INSTALL KIT K53203 22-23 TUNDRA 1.25-3.5" STAGE 13 SUSPENSION SYSTEM BILLET 58770E 1 22-23 TUNDRA 2.5 VS RR CDEV COILOVER KIT 58561DJ 1 22-23 TUNDRA BILLET UCA DJ PRO KIT 55154 1 22-23 TUNDRA SWAY BAR DROP KIT 54002 1 22-23 TUNDRA BILLET REAR LOWER LINK KIT 54102 1 22-23 TUNDRA BILLET REAR UPPER LINK KIT 57840EP 1 22-23 TUNDRA 0-1" REAR 2.5 VS CDEV RR PAIR 53508 1 22-23 TUNDRA IIC INSTALL KIT 3.0 CDEV SUSPENSION STAGES 22-23 TOYOTA TUNDRA 3.0 STAGE 4 SUSPENSION SYSTEMS K53214T 22-23 TUNDRA 2-3.25" STAGE 4 3.0 SUSPENSION SYSTEM TUBULAR 58775E 1 22-23 TUNDRA 3.0 VS RR CDEV COILOVER KIT 58461DJ 1 22-23 TUNDRA TUBULAR UCA DJ KIT 55154 1 22-23 TUNDRA SWAY BAR DROP KIT 54002 1 22-23 TUNDRA BILLET REAR LOWER LINK KIT 54102 1 22-23 TUNDRA BILLET REAR UPPER LINK KIT 57840EP 1 22-23 TUNDRA 0-1" REAR 2.5 VS CDEV RR PAIR 53508 1 22-23 TUNDRA IIC INSTALL KIT K53214 22-23 TUNDRA 1.25-3.25" STAGE 4 3.0 SUSPENSION SYSTEM BILLET 58775E 1 22-23 TUNDRA 3.0 VS RR CDEV COILOVER KIT 58561DJ 1 22-23 TUNDRA BILLET UCA DJ PRO KIT 55154 1 22-23 TUNDRA SWAY BAR DROP KIT 54002 1 22-23 TUNDRA BILLET REAR LOWER LINK KIT 54102 1 22-23 TUNDRA BILLET REAR UPPER LINK KIT 57840EP 1 22-23 TUNDRA 0-1" REAR 2.5 VS CDEV RR PAIR 53508 1 22-23 TUNDRA IIC INSTALL KIT 22-23 TOYOTA TUNDRA 3.0 STAGE 5 SUSPENSION SYSTEMS K53215T 22-23 TUNDRA 2-3.25" STAGE 5 3.0 SUSPENSION SYSTEM TUBULAR 58775E 1 22-23 TUNDRA 3.0 VS RR CDEV COILOVER KIT 58461DJ 1 22-23 TUNDRA TUBULAR UCA DJ KIT 55154 1 22-23 TUNDRA SWAY BAR DROP KIT 54002 1 22-23 TUNDRA BILLET REAR LOWER LINK KIT 54102 1 22-23 TUNDRA BILLET REAR UPPER LINK KIT 57845EP 1 22-23 TUNDRA REAR 3.0 VS RR CDEV PAIR 53508 1 22-23 TUNDRA IIC INSTALL KIT K53215 22-23 TUNDRA 1.25-3.25" STAGE 5 3.0 SUSPENSION SYSTEM BILLET 58775E 1 22-23 TUNDRA 3.0 VS RR CDEV COILOVER KIT 58561DJ 1 22-23 TUNDRA BILLET UCA DJ PRO KIT 55154 1 22-23 TUNDRA SWAY BAR DROP KIT 54002 1 22-23 TUNDRA BILLET REAR LOWER LINK KIT 54102 1 22-23 TUNDRA BILLET REAR UPPER LINK KIT 57845EP 1 22-23 TUNDRA REAR 3.0 VS RR CDEV PAIR 53508 1 22-23 TUNDRA IIC INSTALL KIT
Read More
HERO IN THE MAKING
KIDS T-SHIRT DESIGN CONTEST Would you like to help our Veterans? How about keeping your kids entertained during their summer break? Do both and WIN PRIZES for the whole family! The winning design will be printed on the official Trail Hero 2023 Event Charity T-Shirt with proceeds going to 4 Wheel to Heal veteran programs AND will receive prize packs from contest sponsors! HERE’S HOW: ACTIVITY: Draw a picture about what you think makes a HERO. Maybe its someone you know or someone you have heard about! (PARENTS, PLEASE GUIDE YOUR CHILD THROUGH THE IDEA) Kids 4-15 years of age are eligible. Visit the official contest page for more info.
Read More
NEW PRODUCT - 2023 Ford Super Duty Radius Arm Systems
The ICON Vehicle Dynamics Ford F-250 & F-350 Super Duty Radius Arm System is designed with adjustable caster cams for use with 2.5-3” lifts with the radius arm installed in the factory pivot, eliminating the need for caster bushings. The Radius Arms feature a sealed pivot bushing that minimizes road feedback and ensures a long life and quiet operation. Additionally, their fabricated, fully boxed design ensures strength and utilizes a profile optimized for tire clearance at full steering lock, making a 37” tall tire clear without coming in contact with the radius arm. 64042 2023 FSD RADIUS ARM SYSTEM Key Features: Fully boxed design Built in caster adjustment for optimized return to center Replaceable sealed pivot bushing provides maintenance free operation CNC machined and laser cut steel components Semi-gloss black powder coat finish Ability to have a 5.5” backspace wheel with 37” tires without contact with the arm at steering lock Tech Info: OEM Wheels & Tires Fitment: Yes Recommended Aftermarket Tires: Up to a 37" x 12.50" Recommended Aftermarket Wheels: ICON Alloys | 17x8.5" w/ 5” Backspace / 6mm Offset Recommended Aftermarket Wheels: ICON Alloys | 18x9" w/ 5.25” Backspace / 6mm Offset Recommended Aftermarket Wheels: ICON Alloys | 20x9" w/ 5.25” Backspace / 6mm Offset Tech Note: If lifting over 2.5", adding alignment cams in the knuckle is recommended Complete Radius Arm Suspension Systems Now Available In addition to the Radius Arms themselves, several of our popular "Stage" Suspension Systems are now available featuring the Radius Arms. Our 2.5" Stage 2 through 4 Suspension Systems and 2.5"-3" Stage 2 through 3 Coilover Conversion Systems are listed in the "RADIUS ARM KITS". Stay tuned for more information about these and additional Complete Suspension Systems for 2023 Ford Super Duty, coming soon!
Read More
NEW PRODUCTS - 2020-23 Ford Ranger
ICON is rounding out our suspension compatibility for late 5th-Gen Ford Ranger with the introduction of Upper Control Arms to fit the 2020-23 Rangers that came from the factory equipped with STEEL steering knuckles. Sometime during the 2020 model year Ford switched to a steel knuckle (from aluminum) which had a slightly different tapered bore for the upper ball joint. Existing ICON UCA's (and the associated Suspension Systems) were only compatible with the aluminum knuckles. This New Product Release adds compatibility with the steel knuckle equipped Rangers. Included in this release are both Tubular and Billet versions of ICON Delta Joint UCAs designed to work with the OE steel knuckles, as well as associated variants of our pre-existing Stage 2 through 8 complete suspension systems. DELTA JOINT UPPER CONTROL ARMS (STEEL KNUCKLE) 98511DJ 20-23 RANGER TUBULAR UCA DJ KIT (STEEL KNUCKLE) KEY FEATURES: Features ICON's Patented Delta Joint (U.S. Patent No. 10,731,700) Specifically Designed to fit OE Steel Steering Knuckle 1026 DOM Steel Construction CNC Bent Tubing Serviceable Dual Stage Bushings CNC Machined Bushing Housings and Sleeves Built-In Caster Correction Black Semi-Gloss Powder Coat Finish TECH INFO Compatible with 2020-23 Rangers equipped with OE steel knuckles only. 98521DJ 20-23 RANGER BILLET UCA DJ KIT (STEEL KNUCKLE) KEY FEATURES: CNC machined 6061 billet aluminum construction for light weight and exceptional strength Features ICON's Patented Delta Joint (U.S. Patent No. 10,731,700) Specifically Designed to fit OE Steel Steering Knuckle Camber and caster adjustability allows for precise wheel alignment ICON double adjuster sleeves allow for on-vehicle adjustment Vehicle specific taper pin provides OE-like fitment PTFE Lined 7/8” FK Rod Ends for improved response Built in o-ring sealed dust cover cap TECH INFO Compatible with 2020-23 Rangers equipped with OE steel knuckles only COMPLETE SUSPENSION SYSTEMS In addition to the new Tubular and Billet Upper Control Arms compatible with the OE steel steering knuckles, ICON is also releasing the associated Complete Suspension System "Stages" for 2020-23 Ranger that include these UCAs. These kits differ from the existing kits by the new UCA's only; the remaining components are identical to the aluminum knuckle versions. Please see the detailed information in the downloadable files for complete components lists, pricing, specifications and kit images for each of these kits. Note that the "K Number" (kit number) for each of the stages 2 through 8 are identical to the previous (aluminum knuckle) versions of these kits, but with an "S" appended to the end of the kit number. Previous kits containing UCA's designed for the aluminum knuckles are getting an "A" appended to their K-numbers.
Read More
ICON in Stock
Why wait for months, if not, years? We have INVENTORY! That awesome fact aside, should you come across a back-ordered part, we're currently tracking 4-6 weeks on most items. If that doesn't solve it, you can take advantage of inventory from any of our stocking dealers right now! | DEALER SEARCH
Read More
New From Icon
2023-Up Toyota Sequoia 3" Complete Suspension Systems 2022-Up Toyota Tundra Triple Rate Rear Coil Springs and Associated Complete Suspension Systems ICON Alloys is excited to announce the arrival of our latest wheel design, the Recon SLX ICON Ford Super Duty Suspension Components Carry Over To 2023
Read More
